Synology NAS DS223j 2-bay DiskStation (Diskless)

Synology NAS DS223j 2-bay DiskStation (Diskless)

UPC: 846504004768





Detail Specifications
  CPU
CPU Model
Realtek RTD1619B
CPU Quantity
1
CPU Architecture
64-bit
CPU Frequency
4-core 1.7 GHz
Hardware Encryption Engine
Yes
  Memory
System Memory
1 GB DDR4 non-ECC
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on suppliers product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  Storage
Drive Bays
2
Compatible Drive Type
3.5" SATA HDD
2.5" SATA SSD (with optional 2.5" Disk Holder)
Hot Swappable Drive
-
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  External Ports
RJ-45 1GbE LAN Port
1
USB 3.2 Gen 1 Port
2
Notes
This devices 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
  File System
Internal Drives
Btrfs
ext4
External Drives
Btrfs
ext4
ext3
FAT
NTFS
HFS+
exFAT
Notes
Btrfs file system is available from DSM 7.2-64570.
  Others
System Fan
92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Low-power Mode
Brightness Adjustable Front LED Indicators
Yes
Power Recovery
Yes
Noise Level
18.2 dB(A)
Scheduled Power On / Off
Yes
Wake on LAN / WAN
Yes
Power Supply Unit / Adapter
60 W
AC Input Power Voltage
100V to 240V AC
Power Frequency
50/60 Hz, Single Phase
Power Consumption
16.31 W (Access)
4 W (HDD Hibernation)
British Thermal Unit
55.62 BTU/hr (Access)
13.64 BTU/hr (HDD Hibernation)
Notes
For more information on how power consumption is measured, refer to this article.
Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A) Temperature: 24.25-25.75oC Humidity: 58.2-61.8%
  Temperature
Operating Temperature
0oC to 40oC (32oF to 104oF)
Storage Temperature
-20oC to 60oC (-5oF to 140oF)
Relative Humidity
5% to 95% RH
  Certification
FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
  Environment
RoHS Compliant
  Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
  Optional Accessories
3.5" SATA HDD: HAT3300
Surveillance Device License Pack
Disk Holder: Type C
  Item Dimension (L"xW"xH")
12 x 11 x 5

Weight
5 lbs

Warranty Information
2 years Manufacture



Synology NAS DS223j 2-bay DiskStation (Diskless)

  • Part Number: 14976
  • Brand: Synology
  • Product Sku: DS223J
  • Richmond BC Warehouse:
    261
    Toronto ON Warehouse:
    199
  • Availability: In Stock

  • $286.55

  • Was: $429.83
