eVGA 1600W SuperNOVA 1600 220-T2-1600-X1 T2 80PLUS PLATINUM ATX Power Supply Retail

eVGA 1600W 220-T2-1600-X1 SuperNOVA 1600 T2 80PLUS PLATINUM ATX Power Supply





Detail Specifications
  CABLE LENGTH
ATX CABLE:1x 600mm (m)
EPS CABLE:2x 750mm (m)
PCIE CABLE:5x 750mm, 900mm (m) 4x 750mm (m)
SATA CABLE:4x 550mm, 650mm, 750mm (m), 850mm (m)
FOUR-PIN PERIPHERAL CABLE:2x 550mm, 650mm, 750mm (m)
FLOPPY ADAPTER:2x 100mm
AC POWER:1x 1800mm (m)
MODULAR CABLE TYPE:Full
  CONNECTOR QUANTITY
24 PIN ATX:1x
EPS (CPU):2x 8pin (4+4)
PCIE:9x 8pin (6+2), 5x 6pin
SATA:16x
  POWER SPECS
115 - 240 VAC, 17-10A, 50 - 60 Hz

RAIL/MAX OUTPUT:
+3.3V/24A/120W
+5V/24A/120W
+12V/133.3A/1599.6W
+5Vsb/3A/15W
-12V/0.5A/6W

TOTAL:1600W at +50C
  CONNECTOR QUANTITY
24 PIN ATX:1x
EPS (CPU):2x 8pin (4+4)
PCIE:9x 8pin (6+2), 5x 6pin
SATA:16x
  FOUR-PIN PERIPHERAL
6xv

FLOPPY
2x

ECO MODE
Yes

MTBF
100,000 Hours
  Item Dimension (L"xW"xH"):
7.88 x 5.91 x 4.73

Weight:
10 lb

Warranty Information:
10 Years Manufacture Warranty



eVGA 1600W SuperNOVA 1600 220-T2-1600-X1 T2 80PLUS PLATINUM ATX Power Supply Retail

  • Part Number: 9857
  • Brand: eVGA
  • Product Sku: 220-T2-1600-X1
  • Richmond BC Warehouse:
    Back order
    Toronto ON Warehouse:
    Back order
  • Availability: Call

  • $549.00

  • Was: $823.50
