Intel Pentium Gold G5400 Dual Core 2 Cores 3.7GHz LGA 1151 / H4 / 4MB cache 58W 8th generation / Coffee Lake Desktop Processor BX80684G5400

Intel Pentium Gold G5400 Dual Core 2 Cores 3.7GHz LGA 1151 / H4 / 4MB cache 58W 8th generation / Coffee Lake Desktop Processor BX80684G5400





Detail Specifications
  Essentials
Product Collection: Intel Pentium Gold Processor Series
Code Name: Products formerly Coffee Lake
Vertical Segment: Desktop
Processor Number: G5400
  Performance
Number of Cores: 2
Number of Threads: 4
Processor Base Frequency: 3.70 GHz
Cache: 4 MB
Bus Speed: 8 GT/s DMI3
TDP: 54 W
  Supplemental Information
Embedded Options Available: Yes
  Memory Specifications
Max Memory Size (dependent on memory type): 64 GB
Memory Types: DDR4-2400
Max Number of Memory Channels: 2
Max Memory Bandwidth: 37.5 GB/s
ECC Memory Supported: Yes
  Processor Graphics
Processor Graphics: Intel UHD Graphics 610
Graphics Base Frequency: 350 MHz
Graphics Max Dynamic Frequency: 1.05 GHz
Graphics Video Max Memory: 64 GB
4K Support: Yes, at 60Hz
Max Resolution (HDMI 1.4): 4096x2304 at 24Hz
Max Resolution (DP): 4096x2304 at 60Hz
Max Resolution (eDP - Integrated Flat Panel): 4096x2304 at 60Hz
DirectX Support: 12
OpenGL Support: 4.5
Intel Quick Sync Video: Yes
Intel InTru 3D Technology: Yes
Intel Clear Video HD Technology: Yes
Intel Clear Video Technology: Yes
Number of Displays Supported: 3
Device ID: 0x3E93
  Expansion Options
Scalability: 1S Only
PCI Express Revision: 3.0
PCI Express Configurations: Up to 1x16, 2x8, 1x8+2x4
Max Number of PCI Express Lanes: 16
  Package Specifications
Sockets Supported: FCLGA1151
Max CPU Configuration: 1
Thermal Solution Specification: PCG 2015C (65W)
TJUNCTION: 100oC
Low Halogen Options Available: See MDDS
  Advanced Technologies
Intel Optane Memory Supported: No
Intel Turbo Boost Technology: No
Intel vPro Technology: No
Intel Hyper-Threading Technology: No
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel VT-x with Extended Page Tables (EPT):Yes
Intel TSX-NI: No
Intel 64: Yes
Instruction Set: 64-bit
Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2
Idle States: Yes
Enhanced Intel SpeedStep Technology: Yes
Thermal Monitoring Technologies: Yes
Intel Stable Image Platform Program (SIPP): No
  Security and Reliability
Intel AES New Instructions: Yes
Secure Key: Yes
Intel Software Guard Extensions (Intel SGX): Yes
Intel Memory Protection Extensions (Intel MPX): No
Intel OS Guard: No
Intel Trusted Execution Technology: No
Execute Disable Bit: Yes
Intel Boot Guard: Yes
  Item Dimension ( L inch x W inch x H inch)
5 x 3 x 4
  Weight
1.00 lb
  Warranty Information
3 years Limited Manufacture








Intel Pentium Gold G5400 Dual Core 2 Cores 3.7GHz LGA 1151 / H4 / 4MB cache 58W 8th generation / Coffee Lake Desktop Processor BX80684G5400

  • Part Number: 12563
  • Brand: Intel
  • Product Sku: BX80684G5400
  • Richmond BC Warehouse:
    Back order
    Calgary AB Warehouse:
    Back order
    Markham ON Warehouse:
    246
    Guelph ON Warehouse:
    Back order
    Halifax NS Warehouse:
    Back order
  • Availability: In Stock

  • $78.95

  • Was: $118.43
